Elinchrom Skyport RX radio set
The new ELS Transmitter Speed controls basic functions of BXRI 250/500, Ranger Quadra and D-Lite-it with the built-in ELS Receiver and Elinchrom RX units to which a Transceiver RX is attached.
To control all RX functions of Style RX, Ranger RX, Ranger Quadra RX (Only Ranger Quadra RX with serial numbers from 4001 onwards) and Digital RX from a computer, the USB Transceiver RX 19354 / 19348 and the latest EL Skyport software are required. With this software, additonal features are available such as Strobing, Counter and more.
The Transmitter synchronises remote flash units when each is fitted with either a “Universal” (fitting all flash brands) or the Transceiver RX (fitting Style RX, Digital RX and Ranger RX units) or units with EL-Skyport Tranceiver built-in (BXRi 250/500 & Ranger Quadra AS). The RX Transceiver also provides control over the power and modelling lamp of all Elinchrom RX flash units, directly from the Skyport Transmitter Speed.
Key Features
- +/- Buttons to change flash power settings of RX units and to switch Modelling lamp on/off, without using a computer.
- Test button for manual flash trigger.
- Interference free operation with 40 Bit security.
- Switch to select 8 Frequency Channels --- for example between separate working areas.
- Switch to select 4 Workgroups --- adjusting and synchronising individual units or groups
- Battery life up to 6 Months - over 30’000 flashes
- The “All” switch controls all units in Workgroup 1-4.
- The moveable antenna optimises reception and working distance.
- Compatible with BXRi 250 / 500 and Ranger Quadra AS & D-Lite-it with "onboard" ELS Transceiver.
What's NEW... EL-Skyport SPEED - Added Values
- LED status for EL-Skyport sync mode and battery status.
- Improved housing, battery drawer and switches.
- Improved integrated Hot-shoe with screw lock.
- Improved SYNC-socket for direct connection.
- NORMAL & SPEED Sync modes, please read below..
NEW... Two synchronisation modes, STANDARD and SPEED
- The “Standard” mode is fully compatible with previous EL-Skyport versions.
- The SPEED function is available for Ranger Quadra AS, BXRi 250 / 500 und D-Lite-it and all other units, when used with the Universal Speed.
- Up to 60 m range indoors for STANDARD mode and up to 40 m in SPEED mode.
- Up to 120 m range outdoors for STANDARD mode and up to 60 m in SPEED mode.
- Up to 1/150s shutter speed for SLR cameras in NORMAL mode.
- Up to 1/250s shutter speed for SLR cameras in SPEED mode.
