| Detailed Specifications |
| Display Technology |
Single 0.65" DarkChip2™ DLP® Technology by Texas Instruments |
| Resolution |
Native WXGA (1280 x 800) |
| Maximum Resolution |
WUXGA (1920 x 1200) |
| Brightness (Typical) |
4000 ANSI Lumens |
| Contrast Ratio |
2500:1 (Full On/Full Off) |
| Lamp Life and Type |
3000/2000 Hours (STD/Bright) 280W UHP |
| Throw Ratio |
1.57-2.39:1 (Distance/Width) |
| Projection Distance |
3.9' to 32.8' (1.2 to 10m) |
| Image Size (Diagonal) |
23.2" to 295.7" (0.59 to 7.51m) |
| Aspect Ratio |
16:10 Native, 16:9 and 4:3 Compatible |
| Audio |
Two 2-Watt Speakers |
| Remote Control |
Fully Featured Remote Control w/Mouse and Laser Pointer |
| Displayable Colors |
134.2 Million |
| Keystone Correction |
±30° Vertical |
| Uniformity |
85% |
| Computer Compatibility |
WUXGA, UXGA, SXGA+, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible |
| Video Compatibility |
NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p) |
| Monitor Loop Through |
D-Sub 15-Pin VGA Output (Functional in Both Normal and Standby Modes) |
| Lens Shift |
Vertical 105-130% Offset, Horizontal ±30% Image Width at v="105%" |
| Projection Lens |
F= 2.41~3.2, f = 22.18~33.27 mm, 1.5x Manual Zoom and Focus |
| User Controls |
Complete On-Screen Menu Adjustments in 23 Languages |
| I/O Connectors |
HDMI (Audio Supported), DVI-D w/HDCP, Two VGA-In, VGA-Out, S-Video, Composite Video, Two Mini-Jack Audio-In, RCA Audio-In, Mini-Jack Audio-Out, USB, RS-232, RJ45, +12V Trigger |
| Security |
Kensington® Lock Port, Password Protection, Wireless WEP Key |
| Projection Method |
Front, Rear, Ceiling Mount, Table Top |
| Weight |
12 lbs (5.4kg) |
| Dimensions (W x H x D) |
14.3" x 5" x 11.1" (364 x 127 x 283mm) |
| Noise Level (STD/Bright) |
30dB/32dB |
| Horizontal Scan Rate |
15 - 91 kHz |
| Vertical Refresh Rate |
50 - 85 Hz |
| Operating Temperature |
41 - 95°F (5 - 35°C), 80% Max Humidity, Adjustable Fan Speed for High Altitude Application |
| Power Supply |
AC Input 100-240V, Auto-Switching |
| Standard Accessories |
AC Power Cord, VGA to VGA Cable, USB Cable, RS-232 Cable, Remote Control, Batteries for Remote, Lens Cap, CD-ROM User's Manual, Quick Start Card, Warranty Card |
| Optional Accessories |
Ceiling Mount, S-Video Cable, Audio-Out Adapter, HDMI Cable, Composite Video Cable, DVI Cable, Panoview™ Series Screens |
