| Detailed Specifications |
| Sensor |
16.1 Megapixel, 1/3-inch CMOS |
| Total Pixels |
Approx. 16.8 Megapixels |
| Effective Pixels |
Approx. 16.1 Megapixels |
| Lens Focal Length |
4.3 (W) - 21.5mm (T) (35mm film equivalent: 24 (W) - 120mm (T)) |
| Digital Zoom |
4x |
| Focusing Range |
Auto: 1.2 in. (3cm) - infinity (W), 3.0 ft. (90cm) - infinity (T)
Normal: 2.0 in. (5cm) - infinity (W), 3.0 ft. (90cm) - infinity (T)
Macro: 1.2 in. - 1.6 ft. (W), 3-50cm (W) |
| Autofocus System |
TTL Autofocus |
| Optical Viewfinder |
N/A |
| LCD Monitor |
3.0-inch TFT Colour with wide-viewing angle |
| LCD Pixels |
Approx. 461,000 dots |
| LCD Coverage |
Approx. 100% |
| Maximum Aperture |
f/2.7 (W)-f/5.9 (T) |
| Shutter Speed |
1-1/2000 sec.
15-1/2000 sec. (Total shutter speed range) |
| Sensitivity |
Auto, ISO 100/200/400/800/1600/3200 |
Light Metering Method
|
Evaluative*, Center weighted average, Spot**
* Facial brightness is evaluated in Face AiAF.
** Fixed to center. |
| Exposure Control Method |
AE Lock |
| Exposure Compensation |
+/-2 stops in 1/3-stop increments |
| White Balance Control |
Auto, Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Custom |
| Built-in Flash |
Auto, On, Slow Synchro, Off |
| Flash Range |
1.6 - 11 ft. (W), 3.0 - 6.6 ft. (T) (50cm - 3.5m (W), 90cm - 2.0m (T)) |
| Recycling Time |
10 sec. or less (battery voltage: 3.6 V) |
| Flash Exposure Compensation |
N/A |
| Shooting Modes |
Auto*1, P, Movie Digest, Portrait, Smooth Skin, Smart Shutter*2, High-speed Burst, Handheld Night Scene, Low Light, Fish-eye Effect, Miniature Effect, Toy Camera Effect, Soft Focus, Monochrome, Super Vivid, Poster Effect, Colour Accent, Colour Swap, Underwater, Snow, Long Shutter, Stitch Assist, iFrame Movie, Super Slow Motion Movie
- Shooting movies are possible with the movie button
*1 Smart Auto also available for movies
*2 Smile, Wink Self-timer, Face Self-timer |
| Photo Effects |
My Colours Off, Vivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin, Darker Skin, Vivid Blue, Vivid Green, Vivid Red, Custom Colour*
*Adjustment of contrast, sharpness, saturation, red, green, blue and skin tone are available |
| Self Timer |
Approx. 10-sec. delay/approx. 2-sec. delay/custom*
*Delay time (0-15 sec. (in one-second increments), 20/25/30 sec.) and number of shots (1-10 shots (in one-shot increments)) can be specified. |
| Wireless Control |
N/A |
| Continuous Shooting |
Approx. 2.0 shots/sec. (in P Mode)
Approx. 5.8 shots/sec. (in High-Speed Burst mode)
* Under conditions where the flash does not fire automatically |
| Storage Media |
SD Memory Card, SDHC Memory Card, SDXC Memory Card |
| File Format |
Design rule for Camera File system, DPOF (Version 1.1) compliant |
| Image Recording Format |
Normal, Fine |
| JPEG Compression Mode |
Still Image: Exif 2.3 (JPEG)
Video: MOV (Image: H.264; Audio data; Linear PCM (2 channel monaural)) |
| Number of Recording Pixels |
Still Images:
[16:9]
Large: 4608 x 2592, Medium 1: 3264 x 1832,
Medium 2: 1920 x 1080, Small: 640 x 360
[3:2]
Large: 4608 x 3072, Medium 1: 3264 x 2176,
Medium 2: 1600 x 1064, Small: 640 x 424
[4:3]
Large: 4608 x 3456, Medium 1: 3264 x 2448,
Medium 2: 1600 x 1200, Small: 640 x 480
[1:1]
Large: 3456 x 3456, Medium 1: 2448 x 2448,
Medium 2: 1200 x 1200, Small: 480 x 480
Video:
[iFrame Movie]
1280 x 720 (30 fps*1)
[Super Slow Motion Movie]
640 x 480*2, 320 x 240*3
[Miniature Effect]
1280 x 720*4, 640 x 480*4
[Other than the above]
1920 x 1080 (24 fps*5), 1280 x 720 (30 fps*1), 640 x 480 (30 fps*1)
*1 Actual frame rate is 29.97 fps.
*2 Shooting: 120 fps., Playback: 30 fps*1
*3 Shooting: 240 fps., Playback: 30 fps*1
*4 Shooting: 6 fps, 3 fps, 1.5 fps Playback: 30 fps*1
*5 Actual frame rate is 23.976 fps |
|
Number of Recordable Images
|
| |
16:9 |
3:2 |
4:3 |
| File Size (KB) |
8 GB |
32 GB |
File Size (KB) |
8 GB |
32 GB |
File Size (KB) |
8 GB |
32 GB |
| Large (L) |
SF |
5,184 |
1,506 |
6,081 |
6,144 |
1,272 |
5,136 |
6,912 |
1,131 |
4,567 |
| F |
3,069 |
2,531 |
10,219 |
3,638 |
2,135 |
8,620 |
4,093 |
1,903 |
7,684 |
| Medium 1(M1) |
SF |
2,595 |
2,958 |
11,943 |
3,083 |
2,505 |
10,115 |
3,436 |
2,252 |
9,094 |
| F |
1,537 |
4,912 |
19,826 |
1,825 |
4,162 |
16,802 |
2,060 |
3,721 |
15,020 |
| Medium 2(M2) |
SF |
1,095 |
6,822 |
27,537 |
899 |
8,187 |
33,044 |
1,002 |
7,442 |
30,040 |
| F |
604 |
12,280 |
49,567 |
496 |
14,448 |
58,314 |
558 |
12,927 |
52,176 |
| Small (S) |
SF |
188 |
35,089 |
141,622 |
221 |
30,703 |
123,919 |
249 |
27,291 |
110,150 |
| F |
113 |
49,125 |
198,271 |
133 |
40,937 |
165,225 |
150 |
40,937 |
165,225 |
| Medium* (M) |
SF |
N/A |
N/A |
N/A |
N/A |
N/A |
N/A |
N/A |
N/A |
N/A |
| F |
N/A |
N/A |
N/A |
N/A |
N/A |
N/A |
1,144 |
6,638 |
26,792 |
| |
1:1 |
File Size
(KB) |
8 GB |
32 GB |
| Large (L) |
SF |
5,184 |
1,506 |
6,081 |
| F |
3,069 |
2,531 |
10,219 |
| Medium 1(M1) |
SF |
2,601 |
2,958 |
11,943 |
| F |
1,540 |
4,912 |
19,826 |
| Medium 2(M2) |
SF |
760 |
9,824 |
39,653 |
| F |
420 |
16,374 |
66,090 |
| Small (S) |
SF |
188 |
35,089 |
141,622 |
| F |
133 |
49,125 |
198,271 |
| Medium* (M) |
SF |
N/A |
N/A |
N/A |
| F |
N/A |
N/A |
N/A |
*When in High-Speed Burst or Low Light.
*The approximate number of images recordable on memory cards other than the above can be calculated by using the above figures as a reference and extrapolating accordingly. |
|
Time of Recordable Movies
|
| |
iFrame Movie & Movie Digest |
Miniature Effect |
Super Slow Motion Movie |
| HD: 1280 x 720 |
HD: 1280 x 720 |
640 x 480 |
640 x 480 |
320 x 240 |
| 30 fps*1 |
5x |
10x |
20x |
5x |
10x |
20x |
120 fps*2 |
240 fps*2 |
| 6 fps*2 |
3 fps*2 |
1.5 fps*2 |
6 fps*2 |
3 fps*2 |
1.5 fps*2 |
| Movie Size (KB/sec.) |
4,701 |
573 |
287 |
143 |
246 |
123 |
61 |
4,914 |
2,457 |
| 8GB |
27 min. 39 sec. |
3 hr. 35 min. 27 sec. |
6 hr. 49 min. 22 sec. |
11 hr. 22 min. 17 sec. |
7 hr. 34 min. 51 sec. |
13 hr. 38 min. 45 sec. |
22 hr. 44 min. 36 sec. |
26 min. 24 sec. |
52 min. 28 sec. |
| 32GB |
1 hr. 51 min. 37 sec. |
14 hr. 29 min. 36 sec. |
27 hr. 32 min. 15 sec. |
45 hr. 53 min. 45 sec. |
30 hr. 35 min. 50 sec. |
55 hr. 4 min. 31 sec. |
91 hr. 47 min. 32 sec. |
1 hr. 46 min. 35 sec. |
3 hr. 31 min. 49 sec. |
| |
Other |
| Full HD: 1920 x 1080 |
HD: 1280 x 720 |
640 x 480 |
| 24 fps*3 |
30 fps*1 |
30 fps*1 |
| Movie Size (KB/sec.) |
4,355 |
3,054 |
1,416 |
| 8GB |
29 min. 39 sec. |
42 min. 11 sec. |
1 hr. 28 min. 59 sec. |
| 32GB |
1 hr. 59 min. 43 sec. |
2 hr. 50 min. 19 sec. |
5 hr. 59 min. 10 sec. |
*1 Actual frame rate is 29.97 fps
*2 Playback frame rate is 30 fps
*3 Actual frame rate is 23.976 fps
*The approximate recording time on memory cards other than the above can be calculated by using the above figures as a reference and extrapolating accordingly.
|
| Playback Modes File |
- Stills & Videos: Auto Rotate (Automatic vertical/horizontal detection), Image Advance (Operation Tools, Transition effects, Scroll Display), Rotate, Favorites, My Category, Smart Shuffle, Filtered Playback, Slide Show (Playback Interval, Repeat, Effect, Playlist)
- Still Images: Single, Index (4-100 thumbnails), Magnification (2-10x), Information Display, Red-eye Correction, i-Contrast, Trimming, Resize, My Colours, Focus Check, Histogram, Overexposure Warning
- Videos: Normal Playback*, Slow Motion**, Special Playback, Editing, Resume
*Auto settings available in 5 levels
** 5 levels (including normal playback), sound not available. |
| Erase Modes |
Select image, select range, all images (all filtered images)
- The image data in the memory card stored with the Design rule for Camera File systems format can be erased (however, protected images cannot be erased).
- Using the Movie editing function, sections of the movie (1 sec. increments) can be deleted. - Using the Movie editing function, beginning/end sections of the movie (1 sec. increments) can be deleted. |
| Video Out |
NTSC/PAL (Dedicated connector (female) with unified type of digital, audio and video)?Mini-HDMI connector |
| Audio Out |
Monaural (Dedicated connector (female) unified type of digital, audio, and video) |
| Other |
Mini-HDMI cable: connection to high definition monitor; SD Memory card slot; direct connection to Canon SELPHY Compact Photo Printers, PIXMA Inkjet Photo Printers and PictBridge-compatible printers via camera's USB 2.0 Hi-speed cable |
| Power Source |
1) Rechargeable lithium-ion Battery Pack NB-11L
2) Compact Power Adapter CA-DC10 (included with AC Adapter Kit ACK-DC90 |
| Shooting Capacity |
Approx. 170 shots |
| Playback Time |
Approx. 3 hours |
| Operating Temperature |
32-104°F/0-40°C |
| Operating Humidity |
10-90% |
| Dimensions (W x H x D) |
3.67 x 2.24 x 0.79 in. (93.2 x 57.0 x 20.0mm) |
| Weight |
Approx. 4.76 oz. (135g) (Including the battery and memory card)
Approx. 4.23 oz. (120g) (Camera only) |
