Read Reviews 15 Q & A
Product Highlights
  • 45 MP CMOS Sensor
  • Full-Frame Format
  • 20 fps Continuous Shooting
  • ISO 100-51200 Expandable to 102400
  • 8K @ 30 RAW & 4K @ 120 Video Recording
  • Dual Pixel CMOS AF II Autofocus
  • Sensor-Shift 5-Axis Image Stabilization
  • 10-bit Canon Log HDMI Output
  • Vari-angle LCD Touchscreen
FREE GIFT!
  • Get a Extreme Pro 128GB CFexpress Type B Card (NN), 1700MB/s read & 1200MB/s write speeds with this order $129.99 Value
  • Get a LP-E6NH Battery Pack with this order $119.99 Value
Canon EOS R5 Full Frame Mirrorless Camera Body Canon EOS R5 Full Frame Mirrorless C...
SAVE $800.99   $3,799.00 Add to Cart
FREE SHIPPING Available
Find it for less? Let us know.
Web Availability: In Stock
Product is In Stock in our Warehouse or in one of our store locations. We will confirm stock is available and process your order. If the available stock is sold before your order is processed, you will receive an email from us.
In-store
  • Available in Mississauga
  • Available in Ottawa
  • Available in Toronto
Vistek Locations
  • Toronto In Stock
  • Ottawa In Stock
  • Mississauga In Stock
  • Calgary Available for Order
  • Edmonton On Order
Please call and verify availability at the store as stock changes daily.

Lease this for: $145.50 Learn More

Rent this for: $315/day Learn More

Overview

EOS R5

Discover all the new, enhanced and amazing features in the EOS R5

Including Dual Pixel CMOS AF II, In-body Image Stabilization, 8K video capability, People and Animal Detection and more.

Key Features:

  • High Image Quality featuring a New 45 Megapixel Full-frame CMOS Sensor.
  • DIGIC X Image Processor with an ISO range of 100-51200; Expandable to 102400.
  • High-Speed Continuous Shooting of up to 12 fps with Mechanical Shutter and up to 20 fpsElectronic (Silent) Shutter.
  • Dual Pixel CMOS AF II covering Approx. 100% Area with 1,053 AF Areas.
  • Subject tracking of People and Animals using Deep Learning Technology.
  • 8K RAW, 4K up to 120fps, 10-bit 4:2:2 with Canon Log or HDR PQ, Internal Recording in all Formats, with Auto Focus.
  • In-body Image Stabilizer can provide up to 8 stops of Shake Correction.
  • Dual Card Slots for CF express and UHS-II SD Memory Cards
  • Built-in 0.5” 5.76 Million Dots OLED EVF with 120fps refresh rate, Vari-angle LCD Touchscreen.
  • 2.4/5 Ghz Built-in Wi-Fi®, Bluetooth® Technology.
  • Optional Wireless File Transmitter and Battery Grip.

The EOS R5 builds off of the powerful legacy of Canon’s full frame cameras
Offering next generation refinements in image quality, performance and reliability.

It’s an ideal choice for a large range of photographic and cinematographic environments from weddings, portraits, sports, journalism, landscape, cinematography and more.

Canon’s all-new 45 Megapixel full-frame sensor is at the heart of the EOS R5’s superb image quality, which also leads the way for impressive 8K DCI cinematic movie capture with theability to extract 35.4 Megapixel still images. Focus and speed are paramount in the EOS R5, providing impressive continuous capture at speeds of up to 20 frames-per-second and with Dual Pixel CMOS AF II capability, to track split second movements of eventhe most elusive of subjects. With 1,053 Automatic AF zones, it is easier than ever to photograph people with the use of Eye, Face and Head Detection AF, or intuitively track the whole body, face or eye of cats, dogs, or birds with Animal Detection AF. The 5-axis in-body image stabilization can effectively compensate for camera shake with approximately 8 stops of stabilization with use of certain non-stabilized, and optically image stabilized lenses. Connectivity like 5GHz and 2.4GHz Wi-Fi® and Bluetooth®, is also included.

High Image Quality
Featuring a New 45 Megapixel Full-frame CMOS Sensor

The EOS R5 camera features an entirely new Canon-developed CMOS sensor with approx. 45 effective megapixels.It employs the DIGIC XImage Processor to enhance the speed of operations across the board. This means fast, efficient performance and phenomenal image quality for big prints, impressive 4K video and more.

DIGIC X Image Processor

The EOS R5 camera is the first Canon EOS camera – in the Mirrorless series camera line — to feature a powerful DIGIC X Image Processor, which helps to enhance fine detail in your image.

ISO range of 100-51200
Expandable to 102400 (For still images.)

Delivering high standard and expanded ISOs (for still images), and a score of options to help enhance shooting in varied and fast-changing lighting situations, the EOS R5 camera can shoot at expanded sensitivities down to ISO 50 (L) and up to 102400 (H).


Roberto Valenzuela


Lindsay Adler

High-Speed Continuous Shooting

Up to 12 fps with Mechanical Shutter

Delivering incredible performance at speeds of up to 12 fps, the EOS R5 camera can capture the split-second details between a subject’s movements.  This is ideal for dynamic action photossuch as athletes, animals or vehicles in motion.

Up to 20 fps Electronic (Silent) Shutter

Especially helpful for wildlife photography, journalism and situations where photographers need to remain discrete, the EOS R5 camera features a selectable electronic (silent) shutter mode, and can capture images at up to 20 fps. With a fast AF/AE system, DIGIC X image Processor and high-speed recording with new Dual CF express card slots, the EOS R5 helps ensure that camera operations are performed quickly and precisely.

Canon Ambassador Peter McKinnon and the EOS R5

Dual Pixel CMOS AF II
Covering Approx. 100% Area with 1,053 AF Areas.

High-speed Focusing with Dual Pixel CMOS AF II

The EOS R5 camera’s highly responsive Dual Pixel CMOS AF II system features an incredible 1,053 Automatic AF zones that can be designated as auto-focus focal points (when Face + Tracking priority AF is selected). This ensures higher-precision Eye Detection AF, or allows for you to focus on the desired AF point.  Fast action can be captured and focus can be maintained with speed, accuracy and ease.

AF Area Coverage of Approx. 100% x 100%

The EOS R5 camera features an expansive focus area of approx. 100% horizontal and 100% vertical^2 when working with select RFand EF lenses. With older EF lenses, or with Extender types I and II, the EOS R5 focuses on approx. 80% horizontally and 80% vertically of the image. This means fast and impressive focusing even when composing your subject far from the center of the frame.

*When taking still photos. Actual coverage varies depending on the lens in use.  Focus area will not be covered with the following RF lenses: RF600mm F11 IS STM, RF800mm F11 IS STM.

EV -6 Low-light Autofocus

Amazingfor nighttime photography or in very low light settings, the EOS R5 camera’s brilliant AF can operate in light as dim as a light rating of EV -6^3 where other AF systems may fail or search. Phenomenal AF is achieved even when using lenses with high F numbers. This ultra-sensitive AF works together with the EOS R5’s EVF to clearly capture subjects even when lightis limited.Combined with the EOS R5 camera’s remarkable low-light AF performance, still and video shooting is possible even in dark situations ina variety of places and occasions.

*Camera settings: Center AF point, normal temperature, One-shot AF, ISO 100.

Recording

8K RAW, 4K up to 120fps, 10-bit 4:2:2 with Canon Log or HDR PQ, Internal Recording in all Formats, with Auto Focus

With the high-speed processing capability of the DIGIC Ximage processor, the EOS R5 is ableto record 8K movies (uncropped, atup to 29.97 fps) – a first for Canon full-frame mirrorless cameras. 4K video shooting is also possible at up to 119.9fps, in 4:2:2 10-bit (H.265) Canon Log, and Dual Pixel CMOS AF is available in all 8K and 4K modes. Image-makers worldwide will be able to tell their stories in larger-than-life resolutions. Additional new features include: Internally recorded and uncropped 8K RAW Recording up to 29.97 fps with Dual Pixel CMOS AF, and HDR-PQ Recording (H.265) capability.




Sal Cincotta


Tyler Stableford

Subject tracking of People and Animals
Using Deep Learning Technology

Head and Eye Detection

The EOS R5 camera brings head and eye detection to a new level. Even in situations where a camera may struggleto detect asubject, the EOS R5 camera can locate and a person’s head or eye when people detection is set, allowing ease and accuracy when capturing videos or still images, or while in Live View mode.

Animal Detection

For the first time in a Canon Mirrorless camera, animal detection is now possible. Developed using deep learning technology, the EOS R5 cameracan effectively track the whole body, face, or eye of cats, dogs, or birds for speed and precision – regardless of the animal’s size, posture, or orientation of the face.

* Effectiveness varies depending on the subject. In some cases, dogs, cats or birds may not be detected, while some animals other than dogs, cats or birds may be detected.

In-body Image Stabilizer
Can provide up to 8 stops of Shake Correction

The EOS R5 is Canon’s first camera to incorporate 5-axis IBIS (In-Body Image Stabilization). This camera will not only enhance the ability to shoot still images at slower shutter speeds but it will also help reduce camera shake when shooting movies. Additionally, the EOS R5’s IBIS will work in combination with Optical Image Stabilization found in many Canon RF and EF lenses.

*When combined with certain IS lenses such as the RF24-105mm F4 IS L USM, or when used with certain non-IS lenses as well.



Dual Card Slots
For CF express** and UHS-II SD Memory Cards

Whether you are shooting photos every day, or are recording 8K videos, the EOS R5 camera can capture an incredible amount of images through its super high-speed CF express dual card slots. Plus a UHS-II SD*** card slot is also provided at your disposal.

*Type B compatible.
*Some types of data cannot be saved on the SD memory card.

Built-in 0.5” 5.76 Million Dots OLED EVF
With 120fps refresh rate, Vari-angle LCD Touchscreen

The EOS R5 camera features a high-precision 0.5-inch OLED (Organic Light-Emitting Diode) EVF with approx. 5.76 million dots and a 23mm eyepoint. Displaying a bright image and extensive shooting information that rotates with the camera. The EOS R5’s EVF supports a 120 fps refresh rate^1 and has been created to provide a bright, sharp and colorful 100% view of the subject at hand, displaying a crisp and vivid image with minimal aberration or distortion.

* Display may be grainier.

Vari-angle Touchscreen LCD

The EOS R5 camera features a 3.15-inch, 2.1 Megapixel Clear View LCD II Vari-angle Touchscreen LCD. Its extensive flexibility makes it easy to compose and shoot from virtually any angle, making selfies simple and enablingthe LCD to fold away when not in use. The brightness of the EVF and the LCD monitor can even be adjusted individually. Touch screen features include settings, review and even AF point selection.

Dot-matrix LCD Panel

An LCD panel on the top of the camera features a dot-matrix display that shows information on the camera’s status, recording mode and more. It gives real-time setting information both when the camera is in use or on standby, and can be inverted from black to white to suit viewing preferences or the ambient light source.

2.4/5 Ghz Built-in Wi-Fi®, Bluetooth® Technology

In addition to the traditional 2.4 GHz Wi-Fi®^, the EOS R5 camera now supports 5 GHz Wi-Fi®^ communication – a first for EOS mirrorless cameras. Users can easily perform high-speed FTP data transfer between the camera and using the free Canon Camera Connect app. Simply connect to the Camera Connect app where you can browse, or download images to your smart device, then share and upload from the device directly to various social media sites and web services. For professional photographers using the EOS R5 camera, the built-in Wi-Fi® is the ideal feature that is needed for quick wireless connectivity.

* Compatible with iOS® versions 9.3/10.3/11.2-11.4/12.4/13.2, Android™ smartphone andtablet versions 5.0/5.1/6.0/7.0/7.1/8.0/8.1/9.0/10. Data charges may apply with the download of the free Canon Camera Connect app. This app helps enable you to upload images to social media services. Please note that image files may contain personally identifiable information that may implicate privacy laws. Canon disclaims and has no responsibility for your use of such images. Canon does not obtain, collect or use such images or any information included in such images through this app.

Bluetooth® Capability

Bluetooth connectivity offers continuous connection, and allows the EOS R5 camera to automatically connect to a smart device that is paired with the Canon Camera Connect app. This allows a number of functions from easy image transfer to remote shooting, to adding GPS*3 information to your photos and videos and more.

* Compatible with select smartphone and tablet devices (Android™ version 5.0 or later and the following iOS® devices: iPhone 4s or later, iPad 3rd gen. or later, iPod Touch 5th gen. or later) equipped with Bluetooth® version 4.1 or later and the Camera Connect App Ver. 2.5.10. This application is not guaranteed to operate on all listed devices, even if minimum requirements are met.

* In certain countries and regions, the use of GPS may be restricted. Therefore, be sure to use GPS in accordance with the laws and regulations of your country or region. Be particularly careful when traveling outside your home country. As a signal is received from GPS satellites, take sufficient measures when using in locations where the use of electronics is regulated.

Image.Canon Service

image.canon is a cloud service designed to ease your imaging workflow, whether you are a professional, enthusiast, or casual user. Connecting the EOS R5 camera to the image.canon service will allow photographers to seamlessly upload all images and movies in their original format and quality, and access them from the dedicated app or through a web browser – and automatically forward them to a computer, mobile device, and third party services.

Enhanced Operating Controls

Multi-controller Customization

Designed to allow users to operate customizable camera functions while looking through the optical viewfinder, the EOS R5 camera features a multi-controller button located on the back of the camera that makes it easy for the user to locate and control.

Main Dial and Quick Main Dials1 & 2

With its compact body size, the EOS R5 camera features a three dial User Interface in the main dial, quick control dial 1 and quick control dial 2 which provide direct control over the traditional exposure controls such as Shutter Speed, Aperture, and ISO –and are fully customizable to the user’s preference.

LP-E6NH
High-Capacity Battery Pack

For increased power and the convenience of compatibility among multiple cameras, the EOS R5 camera uses Battery Packs LP-E6NH, the same batteries used on the EOS R camera and others. Especially helpful for photographers with multiple EOS cameras, the Battery Pack LP-E6NHis a robust,long-lasting battery that helps deliver power, shot after shot.

Impressive Durability

Magnesium Body

Comfortable and solid in the hand, the EOS R5 camera features a rigid yet lightweight magnesium alloy chassis that enhances body durability while shielding the camera from electromagnetic radiation and heat. It also has a tempered front panel for internal rigidity.

Shutter Durability

The EOS R5 camera has a durability rated at approx. 500,000 cycles and full-frame focal-plane shutter that offers approx. 12 shots/sec.

Dust-& Water-resistant Sealing

The EOS R5 camera is designed for use in a variety of weather conditions. Sealing materials are used in critical areas like the buttons, terminal covers, the battery compartment and the card slot cover. Precise design and construction help to minimize accidental penetration of dust and moisture in the rest of the camera body. Combined with an RF lens, or any other weather-sealed EF/EF-S lens, the EOS R5 camera proves to be a reliable partner in virtually any climate.

What's Included

EOS R5 Full-Frame Mirrorless Camera Body
Battery Pack LP-E6N
Battery Charger LC-E6
Wide Strap
Cable Protector
Interface Cable IFC-100U
Camera Cover R-F-5

Reviews

Product Specifications

EOS R5

Type

Type

Digital single-lens non-reflex AF/AE camera

Image Processor

DIGIC X



Recording Media

CFexpress card

  • Type B: Card slot

  • SD card speed class-compatible. SD card

  • Compatible with UHS-II

  • Eye-Fi cards and Multimedia cards (MMC) are not supported.



Compatible Lenses

Canon RF lens group (excluding EF, EF-S and EF-M lenses)

When using Mount Adapter EF-EOS R: Canon EF or EF-S lenses (excluding EF-M lenses)

Lens Mount

Canon RF mount

Image Sensor

Type

CMOS sensor (compatible with Dual Pixel CMOS AF)

Effective Pixels

Approx. 45.0 megapixels

Sensor Size

Approx. 36.0 x 24.0 mm

Pixel Size

Approx. 4.40 µm square

Total Pixels

Approx. 47.1 megapixels

Aspect Ratio

3:2 (Horizontal: Vertical)

Color Filter System

RGB primary color filters

Low Pass Filter

Installed in front of the image sensor, non-detachable



Dust Deletion Feature

(1) Self Cleaning Sensor Unit

  • Removes dust adhering to the low-pass filter.

  • At power off only / Enable / Disable. Performed automatically (taking about approx. 2 sec. as indi- cated on the screen) or manually (taking about approx. 8 sec. as indicated on the screen).

  • After manually activated cleaning, the camera will automatically restart (Power OFF to ON).

  • When [Multi Shot Noise Reduction], [Multiple exposures], or [HDR mode] is set, [Clean now] and [Clean manually] cannot be selected.

  1. Dust Delete Data acquisition and appending

    • The coordinates of the dust adhering to the low-pass filter are detected by a test shot and appended to subsequent images.

    • The dust coordinate data appended to the image is used by the EOS Canon Digital Professional Software (v. 4.14 and higher) to automatically erase the dust spots.

    • Not available with EF-S lenses, in cropped shooting or multi-exposure shooting.

(3) Manual cleaning (by hand)

Recording System



Recording Format

Compliant to Design rule for Camera File system 2.0 and Exif 2.3*.

*Supports time difference information in Exif 2.31.

Image Format

JPEG, HEIF, RAW (CR3, 14 bit RAW format), C-RAW (Canon original); Movies: ALL-I, IPB, RAW



File Size

3:2 Aspect Ratio

Large/RAW/C-RAW: 8192 x 5464

Medium: 5808 x 3872

Small 1: 4176 x 2784

Small 2: 2400 x 1600



1.6x (Crop)*

Large/RAW/C-RAW: 5088 x 3392

Small 2: 2400 x 1600



4:3 Aspect Ratio

Large: 7280 x 5464

Medium: 5152 x 3872

Small 1: 3712 x 2784

Small 2: 2112 x 1600

RAW/C-RAW: 8192 x 5464



16:9 Aspect Ratio

Large: 8192 x 4608

Medium: 5808 x 3264

Small 1: 4176 x 2344

Small 2: 2400 x 1344

RAW/C-RAW: 8192 x 5464



1:1 Aspect Ratio

Large: 5456 x 5456

Medium: 3872 x 3872

Small 1: 2784 x 2784

Small 2: 1600 x 1600

RAW/C-RAW: 8192 x 5464



  • Values for Recording Pixels are rounded to the nearest 100,000 or 10,000.

  • For RAW and JPEG images, information outside the cropping area is not retained.

  • JPEG images are generated in the set aspect ratio.

  • RAW images are generated in [3:2], and the set aspect ratio is appended.



* Indicate an inexact proportion.



File Numbering

The following file numbers can be set:

  1. File numbering methods

    1. Continuous numbering

      1. The numbering of captured images continues even after you replace the card.

    2. Auto reset

      1. When you replace the card, the numbering will be reset to start from 0001. If the new SD card already contains images, the numbering will continue from the last recorded image in the card.

  2. Manual reset

a. Resets the file number to 0001, and creates a new folder automatically.

* When manually resetting the file number, folders can also be renamed.

RAW + JPEG / HEIF Simultaneous Recording



Simultaneous recording of any combination of RAW/C-RAW and JPEG/HEIF image-recording quality is supported.

Color Space

Selectable between sRGB and Adobe RGB



Picture Style

  1. Auto

  2. Standard

  3. Portrait

  4. Landscape

  5. Fine Detail

  6. Neutral

  7. Faithful

  8. Monochrome

  9. User Defined 1–3

  • In Scene Intelligent Auto, [Auto] will be set automatically.

  • [Standard] is the default setting for [User Def. 1–3].

White Balance



Settings

  1. Auto (Ambience priority/White priority)

  2. Daylight

  3. Shade

  4. Cloudy*

  5. Tungsten light

  6. White fluorescent light

  7. Flash

  8. Custom (Custom WB)

  9. Color temperature

* Effective also in twilight and sunset.

Auto White Balance

Option between ambience priority and white priority settings.



White Balance Shift

Blue/amber bias: ±9 levels Magenta/green bias: ±9 levels

Corrected in reference to the current WB mode’s color temperature.

Viewfinder

Type

OLED color electronic viewfinder; approx. 5.76 million dots resolution



Coverage

Approx. 100% vertically and horizontally relative to the shooting image area (with image quality L, at approx. 23mm eyepoint).

Magnification / Angle

of View



Approx. 0.76x / Approx. 35.5 degrees (with 50mm lens at infinity, -1 m-1)

Eye Point

Approx. 23mm (at -1 m-1 from the eyepiece lens end)

Dioptric Adjustment Range



Approx. -4.0 to + 2.0 m-1 (dpt)



Viewfinder

Information

  1. Maximum burst

  2. Possible shots/Sec. until self-timer shoots

  3. Focus Bracketing/ Multiple-exposure/HDR shooting/Multi Shot Noise Reduction/Bulb time/Interval timer

  4. Shooting mode

  5. AF method

  6. AF operation

  7. Image quality

  8. Card

  9. Drive mode

  10. Metering mode

  11. No. of remaining shots for focus bracketing, multiple exposures, or interval timer

  12. Electronic level

  13. Movie recording time available

  14. Battery level

  15. Image Stabilizer (IS mode)

  16. Histogram (Brightness/RGB)

  17. Quick Control button

  18. Anti-flicker shooting

  19. White balance/White balance correction

  20. Picture style

  21. Auto Lighting Optimizer

  22. Still photo cropping / Aspect ratio

  23. AF point (1-point AF)

  24. AEB/FEB

  25. View Assist

  26. HDR PQ

  27. Flash ready / FE lock / High-speed sync

  28. Electronic shutter

  29. Touch shutter / Create folder

  30. AE lock

  31. Shutter speed / Multi-function lock warning

  32. Aperture value

  33. Wi-Fi® function

  34. Wi-Fi® signal strength

  35. Bluetooth® function

  36. Exposure simulation

  37. Magnify button

  38. ISO speed

  39. Highlight tone priority

  40. Exposure compensation

  41. Exposure level indicator

Autofocus

Focus Method

Dual Pixel CMOS AF

Number of AF zones available for Automatic Selection

AF area: Horizontal: Approx. 100% x Vertical: Approx. 100% Stills: Max. 1053 zones (39 x 27)

Movies: Max. 819 zones (39 x21)



AF Working Range

EV -6 to 20 (f/1.2 lens*, center AF point, One-Shot AF,at 73°F/23°C, ISO 100)

* Except RF lenses with a Defocus Smoothing (DS) coating.



Focusing brightness range (in movie recording)

8K: EV -3 to 20

4K / Full HD: EV -4 to 20

With an f/1.2 lens*, center AF point, One-Shot AF,at 73°F/23°C, ISO 100

* Except RF lenses with a Defocus Smoothing (DS) coating.



AF Methods



AF Method

Face+Tracking AF

Spot AF

1-point AF

Expand AF Area

(Above, below, left and right/Around)

Zone AF



Large Zone AF: Vertical, Horizontal





Subject to Detect

People, Animals, No Priority

* Available with [AF method] set to Face+Tracking, Zone AF, or Large Zone AF (vertical/horizontal)

Exposure Control



Metering Modes

Real-time metering with image sensor (384 [24x16 zone metering])

  1. Evaluative metering (AF point-linked)

  2. Partial metering (approx. 6.1% of the area at the center of the screen)

  3. Spot metering (approx. 3.1% of the area at the center of the screen)

  4. Center-weighted average metering

Metering Range

EV -3 – 20 (at 73°F/23°C, ISO 100) (Still Photo Shooting)



Exposure Control

Modes

  1. Scene Intelligent Auto

  2. Flexible-priority AE (Fv)

  3. Program AE (P)

  4. Shutter-priority AE (Safety shift possible) (Tv)

  5. Aperture-priority AE (Safety shift possible) (Av)

  6. Manual exposure (M)

  7. Bulb

  8. Custom shooting mode C1, C2, C3





ISO Speed Range

Available ISO speeds; user-set

Normal ISO 100–51200 (in 1/3- or 1-stop increments) Expanded L: equivalent to ISO 50, H: 102400

  • For [Highlight tone priority], the settable ISO speed range will be ISO 200 to 51200.

  • Expanded ISO cannot be set for HDR mode or during HDR PQ shooting.



User-defined ISO range - still photo shooting

ISO Speed Range ISO speed



Minimum L (50)–51200 (in 1-stop increments)



Maximum ISO 100–H (102400) (in 1-stop increments)



* Expanded ISO speeds are noted as being “equivalent” to these speeds.



User-defined Auto ISO range - still photo shooting

Auto Range ISO speed



Minimum ISO 100–25600 (in 1-stop increments)



Maximum ISO 200–51200 (in 1-stop increments)



ISO Auto details in still photo shooting



Shooting mode

No Flash Using Flash



Auto



ISO 100-12800



ISO 100-6400*³

P



ISO 100*¹*²-51200*²



ISO 100*¹*²–6400*²*⁴

TV

AV

M

B

ISO 400*³



  • 1: ISO 200 when [Highlight tone priority] is set to [Enable] or [Enhanced].

  • 2: Varies depending on [Maximum] and [Minimum] of [Auto range].

  • 3: If outside the setting range, changed to the value most close to ISO 400.

  • 4: ISO 1600 when using a lens that is not compatible with “Variable control of maximum ISO Auto limit for E-TTL”.



Exposure Compensa-

tion



Manual ±3 stops in 1/3- or 1/2-stop increments



AEB ±3 stops in 1/3- or 1/2-stop increments



AE Lock

  1. Auto AE lock

    • The metering mode for AE lock after one-shot focus can be customized.

  2. User-applied AE lock

    • In the Fv, P, Tv, Av and M modes, enabled with the AE lock button. (Press again to update.)

    • Enabled in all metering modes.

Shutter



Type

Electronically controlled focal-plane shutter

  1. Electronic first curtain or mechanical shutter

  2. Electronic shutter*

    *Cannot be used in conjunction with the following functions: flash photography, HDR shooting, multiple exposures, Multi Shot Noise Reduction, AEB, HDR PQ, anti-flicker shooting, Dual Pixel RAW shooting, Digital Lens Optimizer [High].

    *A shutter release sound is not generated. However, note that the sounds other than the shutter release sound (aperture, focusing lens drive sound/electronic sound, etc.) may be generated.

    *In electronic shutter shooting under conditions such as flash firing by other cameras or with fluores- cent lighting or other flickering light sources, a strip of light or banding due to the brightness difference may be recorded in the image.



Shutter Speeds

When [Mechanical] or [Elec. 1st- curtain] is set: 1/8000-30 sec, bulb When [Electronic] is set: 1/8000-0.5 sec.



X-sync Speed

Mechanical Shutter: 1/200 sec. Elec. 1st-curtain: 1/250 sec.

Shutter Release

Soft-touch electromagnetic release

Self Timer

10-sec. delay, 2-sec. delay



Shutter Lag Time







Flash



Mechanical Shutter

Electronic 1st curtain

Electronic shutter

Shutter-release time lag

*Measured with shutter button pressed fully from half-pressed position

Not used

Approx. 81 ms

Approx. 50 ms

Approx. 50 ms



Used



N/A



N/A



-

Based on Canon testing standards.

Image Stabilization (IS mode)



Still Photo IS

In-body IS operation can be selected when using a non-IS lens.

  • Always on

  • Only for shot

External Speedlite

E-TTL balance

Ambience priority, standard, flash priority

Compatible E-TTL

Speedlites



Canon EX- and EL-series Speedlites



E-TTL II Flash

Metering

  1. Evaluative (Face Priority)

  2. Evaluative

  3. Average



Slow Sync

(P/Av modes)

(1) 1/250* – 30 sec., auto (2) 1/250* – 1/60 sec., auto

(3) 1/250* sec. (fixed)

  • Electronic 1st curtain shutter only

  • With mechanical shutter — 1/200 sec.

Flash Function Menu

Provided for EX- and EL-series Speedlites

Flash Exposure

Compensation



±3 stops in 1/3- or 1/2-stop increments



Continuous flash

control



  1. E-TTL each shot

  2. E-TTL 1st shot



Drive System



Drive Modes and Continuous Shooting Speed





Drive Modes

Operating Modes

Mechanical Shutter

Electronic 1st curtain

Electronic shutter

Single Shooting

Yes

Yes

Yes



High-speed Continuous + shooting*¹

Mode A*²

Approx. 12 shots/sec.



Approx. 20 shots/sec

Mode B

Approx. 9.2 shots/sec.

Mode C

Approx. 6.8 shots/sec.



High-speed Continuous shooting

Mode A*²

Approx. 6.0 shots/sec.

Approx. 8.0 shots/sec.

Mode B

Approx. 5.1 shots/sec.

Approx. 6.0 shots/sec.

Mode C

Approx. 3.9 shots/sec.

Approx. 4.9 shots/sec.



Low-speed Continuous Shooting

Mode A*²



Approx. 3.0 shots/sec.

Mode B

Mode C

Self-timer:10 sec / remote control

Yes

Self-timer:2 sec / remote control

Yes





  • Automatically switches among modes A (drive mode icon lit in green), B (drive mode icon lit in white), and C (drive mode icon flashing in white).

  • Continuous shooting speed is lower under certain shooting and measurement conditions: shutter speed, aperture value,- subject conditions, brightness, type of lens, timing when internal memory becomes full (temporarily disables shooting)

    • Mechanical / electronic 1st curtain: use of flash, anti-flicker shooting: Enable, Dual Pixel RAW shooting- Enable, type of battery, battery level, temperature, use of a battery grip, use of WFT, use of built-in Wi-Fi.

    • Electronic shutter: State of aperture in continuous shooting

  • With Certain lenses, zooming during continuous shooting with electronic shutter may cause changes in exposure even at the same f/number.

    *1: For shooting RAW images in [High-speed continuous +], 13-bit A/D conversion will apply regardless of the mode (A, B, or C).

    *2: With Anti-flicker shooting, max. continuous shooting speed may drop to approx 6.2 fps (with electronic 1st curtain shut- ter) or approx. 4.9 fps (with mechanical shutter)\.

  • For Dual Pixel RAW shooting, Low-speed continuous shooting will apply.





Still Shooting with Mechanical Shutter or electronic 1st-curtain shutter, shot at approx. 12 fps







Image Quality

Maxiumum Burst [Approx.]



SD Card (UHS-I)

SD Card [High-speed] (UHS-II)



CFexpress Card



JPEG*4



L (fine)



190



350



350

HEIF*³

L (fine)

190

280

280



RAW*4

RAW

66

87

180

C-RAW

130

260

260



RAW+- JPEG*4

RAW +

L (fine)

64

79

160

C-RAW +

L (fine)

100

130

240



RAW+HEIF*³

RAW +

L (fine)

61

74

90

C-RAW +

L (fine)



110



140



140





Still photo file size / Number of possible shots / Maximum burst for continuous shooting









With Electronic shutter, shot at approx. 20 fps





Image Quality

Maxiumum Burst

CFexpress Card



JPEG*4



L (fine)



170



RAW*4

RAW

83

C-RAW

130



RAW+- JPEG*4

RAW + L (fine)

84

C-RAW + L (fine)

150











*¹: The number of possible shots and maximum burst (SD card) apply to a 32 GB SD card based on Canon testing standards.

*²: The number of shots available and maximum burst (CFexpress card) apply to a 325 GB CFexpress card conforming to Canon testing standards.

*³: Available when [HDR PQ] for HDR shooting is set to [Enable].

*⁴: When [HDR PQ] for HDR shooting is set to [Disable].

*⁵: With mechanical shutter or electronic 1st-curtain shutter, shot at approx. 12 fps.

* File size, number of possible shots, and maximum burst vary depending on shooting conditions (including 1.6x crop/aspect ratio, subject, memory card brand, ISO speed, Picture Style, and Custom Function).

HDR Shooting

HDR PQ Shooting

Disable / Enable



Still Photo HDR PQ



Recording format HEIF



Bit depth 10 bit



Color sampling method YCbCr 4:2:2



HDR specification ITU-R BT.2100 (PQ)



Movie HDR PQ



Recording format mp4



Bit depth 10 bit



Color sampling method YCbCr 4:2:2



HDR specification ITU-R BT.2100 (PQ)

HDR Mode-

Continuous Shooting

  1. 1 shot only

  2. Continuously





Video Shooting



File Format

Normal Movies



Canon Log

OFF

ON

HDR PQ

OFF

ON

OFF

Container format

MP4

Bit depth

8 bit

10 bit

10 bit

Compres- sion

8K

H.265/HEVC



H.265 / HEVC



H.265 / HEV

4K / Full HD

H.264 / MPEG-4 AVC

Video signal recording range



Full range (0-255)



Full range (0-1023)



Full range (128-1016)

Color sampling method

YCbCr 4:2:0

YCbCr 4:2:2

YCbCr 4:2:2



Color Matrix



Rec.ITU-R BT.709



Rec.ITU-R BT.2020

Rec.ITU-R BT.709/ BT.2020



Audio

ALL-I / IPB

AAC / Linear PCM*

IPB (light)

AAC

* Selection of AAC and Linear PCM is supported [C.Fn 4-2: Audio compression]

RAW Movies



Canon Log

OFF

ON

HDR PQ

OFF

ON

OFF

Container format

RAW (CRM)

Bit depth

12 bit

Audio

Linear PCM

Simultaneous movie re- cording (4K DCI)



MP4



MP4 (10 bit)





4K HQ movies (4K Fine)

High-quality 4K mode movies from 8K readout oversampling.

  • Uses the highest frame rate (29.97 fps).

  • SD card recording supported.

  • EF-S cropping not supported.





Video Recording Size and Frame Rates



Movie-recording Quality



8K DCI



29.97 fps

24.00 fps

23.98 fps

RAW ALL-I IPB



8K UHD

29.97 fps

23.98 fps

ALL-I IPB



4K DCI

(Movie cropping [Disable/Enable])

59.94 fps

29.97 fps

24.00 fps

23.98 fps



ALL-I IPB

4K DCI (High Frame Rate)

119.88 fps

ALL-I

4K (UHD)

(Movie cropping [Disable/Enable])

59.94 fps

29.97 fps

23.98 fps

ALL-I IPB

4K UHD (High Frame Rate)

119.88 fps

ALL-I



Full HD

(Movie cropping [Disable/Enable])

59.94 fps

29.97 fps

23.98 fps



ALL-I IPB

29.97 fps

IPB (Light)





Continuous Shooting Time

Canon Log: Off, HDR PQ: Off



Video Recording Size

Total Recording Time (approx.)

Bit Rate/File Size

(approx.)

64 GB

256 GB

1 TB



8K DCI



29.97 fps

25.00 fps

24.00 fps

23.98 fps



RAW



3 min.



13 min.



51 min.

2600 Mbps

18668 MB/min.



ALL-I



6 min.



26 min.



1 hr. 42 min.

1300 Mbps

9309 MB/min.



IPB



18 min.

1 hr. 12 min.



4 hr. 42 min.

470 Mbps

3373 MB/min.



8K UHD



29.97 fps

25.00 fps

23.98 fps



ALL-I



6 min.



26 min.



1 hr. 42 min.

1300 Mbps

9309 MB/min



IPB



18 min.

1 hr. 12 min.



4 hr. 42 min.

470 Mbps

3373 MB/min.



4K DCI



59.94 fps

50.00 fps



ALL-I



9 min.



36 min.



2 hr. 21 min.

940 Mbps

6734 MB/min.



IPB



36 min.

2 hr. 27 min.



9 hr. 35 min.

230 Mbps

1656 MB/min.



4K DCI

4K HQ - FINE



29.97 fps

25.00 fps

24.00 fps

23.98 fps



ALL-I



18 min.

1 hr. 12 min.



4 hr. 42 min.

470 Mbps

3373 MB/min.



IPB

1 hr. 10 min.

4 hr. 40 min.



18 hr. 17 min.

120 Mbps

869 MB/min.



4K DCI

119.88 fps

100.00 fps



ALL-I



4 min.



18 min.



1 hr. 10 min.

1880 Mbps

13447 MB/min.



4K UHD



59.94 fps

50.00 fps



ALL-I



9 min.



36 min.



2 hr. 21 min.

940 Mbps

6734 MB/min.



IPB



36 min.

2 hr. 27 min.



9 hr. 35 min.

230 Mbps

1656 MB/min.



4K UHD

4K UHD HQ - Fine



29.97 fps

25.00 fps

23.98 fps



ALL-I



18 min.

1 hr. 12 min.



4 hr. 42 min.

470 Mbps

3373 MB/min.



IPB

1 hr. 10 min.

4 hr. 40 min



18 hr. 17 min.

120 Mbps

869 MB/min.



4K UHD

119.88 fps

100.00 fps



ALL-I



4 min.



18 min.



1 hr. 10 min.

1880 Mbps

13447 MB/min.



Full HD



59.94 fps

50.00 fps



ALL-I



47 min.

3 hr. 8 min.

12 hr. 14

min.

180 Mbps

1298 MB/min



IPB

2 hr. 18 min.

9 hr. 14 min.



36 hr. 6 min.

60 Mbps

440 MB/min.



29.97 fps

25.00 fps

23.98 fps



ALL-I

1 hr. 33 min.

6 hr. 12 min.

24 hr. 16

min.

90 Mbps

655 MB/min.



IPB

4 hr. 30 min.

18 hr. 2 min.

70 hr. 27

min.

30 Mbps

655 MB/min.

29.97 fps

25.00 fps



IPB (Light)

11 hr. 35

min.

46 hr. 23

min.

181 hr. 13

min.

12 Mbps

88 MB/min.



Time- lapse movies



8K



29.97 fps

25.00 fps



ALL-I



6 min.



26 min



1 hr. 42 min.

1300 Mbps

9298 MB/min.



4K



18 min.

1 hr. 12 min.



4 hr. 43 min.

470 Mbps

3362 MB/min.



Full HD

1 hr. 34 min.

6 hr. 19 min.

24 hr. 41

min.

90 Mbps

644 MB/min.





Continuous Shooting Time, Continued.

Canon Log: On or HDR PQ: On



Video Recording Size

Total Recording Time (approx.)

Bit Rate/File Size

(approx.)

64 GB

256 GB

1 TB



8K DCI



29.97 fps

25.00 fps

24.00 fps

23.98 fps



RAW



3 min.



13 min.



51 min.

2600 Mbps

18668 MB/min.



ALL-I



6 min.



26 min.



1 hr. 42 min.

1300 Mbps

9309 MB/min.



IPB



12 min.



50min.



3 hr. 15 min.

680 Mbps

4875 MB/min.



8K UHD



29.97 fps

25.00 fps

23.98 fps



ALL-I



6 min.



26 min.



1 hr. 42 min.

1300 Mbps

9309 MB/min



IPB



12 min.



50 min.



3 hr. 15 min.

680 Mbps

4875 MB/min.



4K DCI



59.94 fps

50.00 fps



ALL-I



8 min.



34 min.



2 hr. 13 min.

1000 Mbps

7164 MB/min.



IPB



24 min.

1 hr. 39 min.



6 hr. 30 min.

340 Mbps

2443 MB/min.



4K DCI

4K HQ - FINE



29.97 fps

25.00 fps

24.00 fps

23.98 fps



ALL-I



18 min.

1 hr. 12 min.



4 hr. 42 min.

470 Mbps

3373 MB/min.



IPB



49 min.

3 hr. 18 min.

12 hr. 57

min.

170 Mbps

1227 MB/min.



4K DCI

119.88 fps

100.00 fps



ALL-I



4 min.



18 min.



1 hr. 10 min.

1880 Mbps

13447 MB/min.



4K UHD



59.94 fps

50.00 fps



ALL-I



8 min.



34 min.



2 hr. 13 min.

1000 Mbps

7164 MB/min.



IPB



24 min.

1 hr. 39 min.



6 hr. 30 min.

340 Mbps

2443 MB/min.



4K UHD

4K UHD HQ - Fine



29.97 fps

25.00 fps

23.98 fps



ALL-I



18 min.

1 hr. 12 min.



4 hr. 42 min.

470 Mbps

3373 MB/min.



IPB



49 min.

3 hr. 18 min

12 hr. 57

min.

170 Mbps

1227 MB/min.



4K UHD

119.88 fps

100.00 fps



ALL-I



4 min.



18 min.



1 hr. 10 min.

1880 Mbps

13447 MB/min.



Full HD



59.94 fps

50.00 fps



ALL-I



36 min.

2 hr. 27 min.



9 hr. 35 min.

230 Mbps

1656 MB/min



IPB

1 hr. 33 min.

6 hr. 12 min.

24 hr. 16

min.

90 Mbps

655 MB/min.



29.97 fps

25.00 fps

23.98 fps



ALL-I

1 hr. 2 min.

4 hr. 9 min.

16 hr. 16

min.

135 Mbps

977 MB/min.



IPB

3 hr. 3 min.

12 hr. 13

min.

47 hr. 45

min.

45 Mbps

333 MB/min.

29.97 fps

25.00 fps



IPB (Light)

5 hr. 1 min.

20 hr. 7 min.

78 hr. 37

min.

28 Mbps

202 MB/min.



Time- lapse movies



8K



29.97 fps

25.00 fps



ALL-I



6 min.



26 min



1 hr. 42 min.

1300 Mbps

9298 MB/min.



4K



18 min.

1 hr. 12 min.



4 hr. 43 min.

470 Mbps

3362 MB/min.



Full HD

1 hr. 3 min.

4 hr. 12 min.

16 hr. 27

min.

135 Mbps

966 MB/min.

* Bit rate indicates video output only, audio is not included.

*Movie recording is interrupted if the maximum recording time per movie, 29 min. 59 sec., is exceeded. (Time is different for High Frame Rate movies.)

*8K movie recording (RAW, DCI, UHD) has restrictions on possible recording time due to the temperature rise. Max possible recording time is approx. 20 min. (at room temperature).

*4K 60p movie copped recording has restrictions on possible recording time due to the temperature rise. Max possible recording time is approx. 25 min. (at room temperature).

*Sound is not recored for approx. the last two frames when the compression method for movie recording quality is IPB or IPB-Light (audio:AAC) or [C.Fn 4-2 Audio compression] is set to [Enable]. Moreover, the video and sound may be slightly out of sync when movies are played back in Windows.



Card Performance Requirements









Movie Recording Size



CFexpress

card

SD Card

8 bit

10 bit



8K



8K RAW



RAW



Refer to the Canon Website



-



8K

ALL-I



-



IPB



Video Speed Class 60 or higher



Video Speed Class 90 or higher



4K

119.88 fps

100.00 fps



ALL-I



-



59.94 fps

50.00 fps



ALL-I



-

IPB

Video Speed Class 30 or higher

Video Speed Class 60 or higher



Other than

above



ALL-I

Video Speed Class 60 or higher

Video Speed Class 60 or higher



IPB

UHS Speed Class 3 or higher

UHS Speed Class 3 or higher



Full HD



119.88 fps

100.00 fps



ALL-I



UHS Speed Class 3 or higher

Video Speed Class 60 or higher



59.94 fps

50.00 fps



ALL-I

SD Speed Class 6 or higher

UHS Speed Class 3 or higher



IPB

SD Speed Class 10 or higher

UHS Speed Class 3 or higher



Other than

above



ALL-I

UHS Speed Class 3 or higher

UHS Speed Class 3 or higher



IPB

SD Speed Class 6 or higher

SD Speed Class 6 or higher

IPB (Light)

SD Speed Class 4 or higher

SD Speed Class 4 or higher



Time-lapse movies

8K



ALL-I

-

4K

Video Speed Class 60 or higher

Video Speed Class 60 or higher



Full HD



UHS Speed Class 3 or higher



UHS Speed Class 3 or higher



* With Movie cropping set to [Disable], Movie digital IS set to [Off].

Focusing

Dual Pixel CMOS AF

Exposure Compensation



±3 stops in 1/3- or 1/2-stop increments

LCD Screen

Type

TFT color, liquid-crystal monitor



Monitor Size

3.2-inch (screen aspect ratio of 3:2)

3.15 in./8.01cm diagonal (2.63 in./6.67cm width, 1.75 in./4.44cm height)

Dots

Approx. 2.1 million dots

Coverage

Approx. 100% vertically/horizontally

Brightness Control

Manually adjustable to one of seven brightness levels



Coating

Clear View LCD II

  • Anti-smudge coating applied.

  • Anti-reflection coating not applied.



Interface Languages

29 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Ukraine, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, Romanian, Turkish, Arabic, Thai, Simplified/Traditional Chinese, Korean, Malay, Indonesian, Japanese)

Playback



Display Format





Item

Still Photo

Movie

Magnify zoom display

1.5x–10x (5 levels)

-

AF point display

Yes

-

Grid display

Off / 3×3 / 6×4 / 3×3+diag

-



Rating

OFF / 1 to 5 Stars

Select images / Select range / All images in folder / All images on card / All found images

Image Search

Search conditions

Rating / Date / Folder / Protect / Type of file

Protect

Select images / Select range / All images in folder / Unprotect all images in folder / All images on card / Unprotect all images on card / All found images

In-camera RAW image

processing



Supported



-

Resizing

Supported

-

Cropping

Supported

-



Highlight Alert

The white areas with no image data will blink.

Histogram

Brightness and RGB

Quick Control Function

Function

The Quick Control screen is accessed by pressing the Quick Control button during still photo shooting.

Image Protection and Erase



Protection

  1. Single image (select image)

  2. Select range

  3. All images in a folder

  4. All images on card

    • Image browsing and image search can be based on ratings.

    • Ratings-based image selections also possible with DPP.

  5. All found images (only during image search)



Erase

Except protected images

  1. Select images to erase

  2. Select range

  3. All images in folder

  4. All images on card

  5. All found images (only during image search)

Direct Printing

Compatible Printers

Not supported

DPOF: Digital Print Order Format

DPOF

Compliant to DPOF Version 1.1

Wi-Fi®

Standards Compliance

IEEE 802.11a/ac/b/g/n



Transmission Method

DS-SS modulation (IEEE 802.11b) OFDM modulation (IEEE 802.11g/n/a/ac)



Transition Frequency

(Central Frequency)

2.4 GHz band

Frequency: 2412 to 2462 MHz

Channels: 1 to 11 channels



5 GHz band

Frequency: 5180 to 5825 MHz

Channels: 36 to 165 channels



Connection Method

  1. Camera access point mode

  2. Infrastructure mode



Security





Connection Method



Encryption

Authentication

Encryption

Key Format and Length



Camera Access Point

WPA2-PSK

AES

  • ASCII 8 characters

Open

Disable



Infrastructure



Open



WEP

  • Hexadecimal 10 digits

  • Hexadecimal 26 digits

  • ASCII 5 characters

  • ASCII 13 characters

Disable

Shared key

WEP

Same as WEP above

WPA-PSK

TKIP AES

  • Hexadecimal 64 digits

  • ASCII 8–63 characters

WPA2-PSK





Communication with a Smartphone

Images can be viewed, controlled, and received using a smartphone.

Remote control of the camera using a smartphone is possible depending on the Camera Connect specifications.

Images can be sent to a smartphone.

Remote Operation Using EOS Utility



The camera can be controlled via Wi-Fi® using EOS Utility.

Print from Wi-Fi®

Printers



Not supported.



Send Images to a Web

Service

Still photos (RAW, C-RAW, HEIF, and JPEG) and movies (MP4) can be uploaded to image.canon server album.

With the image.canon server, images can be sent to social media or a photo album link can be sent (by the image.canon specifications).

Bluetooth®

Standards Compliance

Bluetooth Specification Version 5.0 compliant (Bluetooth low energy technology)

Transmission Method

GFSK modulation



Customization

Custom Functions

2 Custom Functions are settable.



Custom Controls

Customizable Buttons

Shutter button Movie button MODE button AF-ON button AE lock button AF point button

Depth of field preview button Lens AF stop button Multi-function button

LCD panel illumination button Set button

Multi-controller



Customizable Dials

Main dial

Quick control dial 1 & 2

Control ring



My Menu Registration

My Menu tab overall operations

• Adding a tab

• Deleting tabs in a batch

• Deleting all tab items

• Setting the menu display

My Menu tab detailed operations

• Selecting a registered item

• Sorting registered items

• Deleting selected registered items

• Deleting registered items in a batch

• Deleting tabs

• Changing a tab name (16 ASCII characters)

  • Up to six top-tier menu items and Custom Functions can be registered.

  • Up to five My Menu tabs can be added.

Interface



USB Terminal

Equivalent to Hi-Speed USB (USB 3.1 Gen 2)

  • For PC communication

  • Terminal type: USB Type-C

  • Shared with terminal for in-camera charging with USB Power Adapter PD-E1.

  • In-camera Charging: Equivalent to USB type-C (5 V/1.5 A), but use should be restricted to USB Power Adapter PD-E1.



Video Out Terminal

HDMI micro OUT terminal Type D (Resolution switches automatically) / CEC not compatible

  • Images can be displayed through the HDMI output and on screen at the same time.

  • Images will not be displayed unless [NTSC] or [PAL] is properly set according to the video system of the TV set.

Microphone input terminal



3.5mm diameter stereo mini jack

Headphone terminal

3.5mm diameter stereo mini jack

Power Source



Battery

LP-E6NH/LP-E6N/LP-E6

  • With the AC Adapter AC-E6N + DC Coupler DR-E6, AC power is possible.

  • With the USB Power Adapter PD-E1, in-camera charging of LP-E6NH is possible. The USB Power Adapter PD-E1 is not compatible with powering the camera.



Battery Check

Automatic battery check when the power switch is turned ON. Displayed in 6 levels on top LCD panel.

  • Battery level can be checked on the LCD panel and in the viewfinder. Battery Info display in Set-up Menu:

  • Type of power source used.

  • Remaining capacity (percentage of battery charge remaining).

  • Recharge performance: (3-level display of battery's ability to hold a charge)



Start-up Time

Approx. 0.4 sec.

  • Based on CIPA testing standards.

Physical Specs

Dimensions

(W x H x D)

Approx. 138 x 97.5 x 88 mm (5.45 x 3.84 x 3.46")

  • Based on CIPA standards.



Weight

Approx. 738 g (1.63 lbs)
*Including battery, SD memory card; without body cap

Approx. 650 g (1.43 lbs)
* Body only; without battery, card or body cap

Operating Environment

Working Temperature Range

32–104°F / 0–+40°C

Working Humidity Range

85% or less

Questions & Answers

Canon EOS R5 Full Frame Mirrorless Camera Body

Looking for a personal touch? Not sure if you are choosing the right product? Our staff is here to help.

We want to make sure you get the right product for your needs.
Our staff will help you understand the options available so you can be confident in your purchase.

As the country’s leading Professional Imaging retailer, Vistek is in the perfect position to ensure you make the right choice.
Contact us today for a personal touch.
