Canon EOS R7 with RF-S18-150mm F3.5-6.3 IS STM

Digital single-lens non-reflex AF/AE camera

DIGIC X

SD card

• SD card speed class-compatible.
• Compatible with UHS-II
• Eye-Fi cards and Multimedia cards (MMC) are not supported.

Canon RF-S/RF lens group (excluding EF, EF-S and EF-M lenses)

When using Mount Adapter EF-EOS R: Canon EF or EF-S lenses (excluding EF-M lenses)

Canon RF mount

CMOS sensor (compatible with Dual Pixel CMOS AF)

Approx. 32.5 megapixels

Approx. 22.3 x 14.8 mm

Approx. 3.2 µm square

Approx. 34.4 megapixels

3:2 (Horizontal: Vertical)

RGB primary colour filters

Installed in front of the image sensor, non-detachable

(1) Self Cleaning Sensor Unit

• Removes dust adhering to the low-pass filter.
• At power off only / Enable / Disable. Performed automatically (taking about approx. 2 sec. as indicated on the screen) or manually (taking about approx. 7 sec. as indicated on the screen).
• After manually activated cleaning, the camera will automatically restart (Power OFF to ON).
• When [Multi Shot Noise Reduction], [Multiple exposures], or [HDR mode] is set, [Clean now] and [Clean manually] cannot be selected.

(2) Dust Delete Data acquisition and appending

• The coordinates of the dust adhering to the low-pass filter are detected by a test shot and appended to subsequent images.
• The dust coordinate data appended to the image is used by the EOS Canon Digital Professional Software to automatically erase the dust spots
• Not available in focus bracketing, RAW burst mode, or multiple-exposure shooting.

(3) Manual cleaning (by hand)

Compliant to Design rule for Camera File system 2.0 and Exif 2.31*

*Supports time difference information.

Still: JPEG, HEIF, RAW, Dual Pixel RAW, Raw Burst, C-RAW (CR3);

Movies: ALL-I*, IPB, IPB Light

* Time-lapse movies only

(1) 1 shot only

(2) Every Shot

(1) Focus Bracketing

(2) Interval Timer

(3) Bulb Timer

(4) Multi-Shot NR

3:2 Aspect Ratio
Large/HEIF/RAW: 6960 x 4640
Medium: 4800 x 3200
Small 1: 3472 x 2320*
Small 2: 2400 x 1600

4:3 Aspect Ratio
Large: 6160 x 4640*
Medium: 4256 x 3200*
Small 1: 3072 x 2320*
Small 2: 2112 x 1600*
RAW: 6960 x 4640

16:9 Aspect Ratio
Large: 6960 x 3904*
Medium: 4800 x 2688*
Small 1: 3472 x 1952*
Small 2: 2400 x 1344*
RAW: 6960 x 4640

1:1 Aspect Ratio
Large: 4640 x 4640
Medium: 3200 x 3200
Small 1: 2320 x 2320
Small 2: 1600 x 1600
RAW: 6960 x 4640

• Values for Recording Pixels are rounded to the nearest 100,000th.
• RAW/C-RAW images are generated at 3:2, with information added about the specified aspect ratio, and JPEG images are generated at the specified aspect ratio.
• These aspect ratios (M / S1 / S2) and pixel counts also apply to resizing.

* Indicate an inexact proportion.

The following file numbers can be set:

1. File numbering methods
   • Continuous numbering
     • The numbering of captured images continues even after you replace the card.
   • Auto reset
     • When you replace the card, the numbering will be reset to start from 0001. If the new SD card already contains images, the numbering will continue from the last recorded image in the card.

Simultaneous recording of any combination of RAW/C-RAW and JPEG/HEIF image-recording quality is supported.

Selectable between sRGB and Adobe RGB

(1) Auto

(2) Standard

(3) Portrait

(4) Landscape

(5) Fine Detail

(6) Neutral

(7) Faithful

(8) Monochrome

(9) User Defined 1–3

(1) Auto (Ambience priority/White priority)

(2) Daylight

(3) Shade

(4) Cloudy¹

(5) Tungsten light

(6) White fluorescent light

(7) Flash

(8) Custom² (Custom WB)

(9) Colour temperature

¹ Effective also in twilight and sunset.

² Setting method options include [Custom White Balance] and [Shoot to set WB].

Option between ambience priority and white priority settings.

Blue/amber bias: ±9 levels

Magenta/green bias: ±9 levels

• Corrected in reference to the current WB mode’s color temperature.
• Blue/amber and magenta/green shift can be set at the same time.

OLED colour electronic viewfinder; approx. 2.36 million dots resolution

Approx. 100% vertically and horizontally relative to the shooting image area (with image quality L, at approx. 22mm eyepoint).

Approx. 1.15x / Approx. 33 degrees (with 3:2 display, an 50mm lens at infinity, -1 m^-1)

Approx. 22mm (at -1 m^-1 from the eyepiece lens end)

Approx. -4.0 to + 2.0 m^-1 (dpt)

Dual Pixel CMOS AF

AF area: Horizontal: Approx. 100% x Vertical: Approx. 100%

Stills: Max. 651 zones (39 x 21)

Movies: Max. 527 zones (39 x 17)

EV -5 to 20 (f/1.2 lens*, center AF point, One-Shot AF,at room temperature, ISO 100)

* Except RF lenses with a Defocus Smoothing (DS) coating.

Full HD 29.97fps : EV -3.5 to 20

With an f/1.2 lens*, center AF point, One-Shot AF,at room temperature, ISO 100

* Except RF lenses with a Defocus Smoothing (DS) coating.

Whole area AF

Spot AF

1-point AF

Expand AF Area (Above, below, left and right/Around)

Expand AF Area: Around

Flexible Zone AF 1,2,3

People, Animals, Vehicles, No Priority

* Available with [AF Area] set to Whole area AF

AF / MF

• Applies when an RF or RF-S lens without a focus mode switch is attached.
• When lenses with a focus mode switch are attached, the setting on the lens takes precedence.

Real-time metering with image sensor (384 zones [24x16 zone metering])

(1) Evaluative metering

(2) Partial metering (approx. 6.0% of the area at the center of the screen)

(3) Spot metering (approx. 3.0% of the area at the center of the screen)

(4) Center-weighted average metering

Still Photo Shooting : EV -2 to 20 (at room temperature, ISO 100)

Movie Recording: EV 0 to 20 (at room temperature, ISO 100)

Available ISO speeds; user-set

Normal: ISO 100–32000 (in 1/3- or 1-stop increments)

Expanded: H (equivalent to ISO 51200)

• For [Highlight tone priority], the settable ISO speed range will be ISO 200 to 32000.
• Expanded ISO cannot be set for HDR mode or during HDR PQ shooting.

User-defined ISO range - still photo shooting

* Expanded ISO speeds are noted as being “equivalent” to these speeds.

User-defined Auto ISO range - still photo shooting

ISO Auto details in still photo shooting

* 1: ISO 200 when [Highlight tone priority] is set to [Enable] or [Enhanced].

* 2: Varies depending on [Maximum] and [Minimum] of [Auto range].

* 3: If outside the setting range, changed to the value most close to ISO 400.

(1) Auto AE lock

• The metering mode for AE lock after one-shot focus can be customized.

(2)User-applied AE lock

• In the Fv, P, Tv, Av and M modes, enabled with the AE lock button. (Press again to update.)
• Enabled in all metering modes.

(1) Mechanical

(2) Electronic 1st-Curtain

(3) Electronic Shutter (1st and 2nd curtain - silent*)

* Cannot be used in conjunction with the following functions: flash photography, HDR shooting, multiple exposures, Multi Shot Noise Reduction, AEB, HDR PQ, anti-flicker shooting, Dual Pixel RAW shooting, Digital Lens Optimizer [High].

* A shutter release sound is not generated. However, note that the sounds other than the shutter release sound (aperture, focusing lens drive sound/electronic sound, etc.) may be generated.

* In electronic shutter shooting under conditions such as flash firing by other cameras or with fluorescent lighting or other flickering light sources, a strip of light or banding due to the brightness difference may be recorded in the image.

When [Mechanical] or [Elec. 1st- curtain] is set: 1/8000-30 sec, bulb

When [Electronic] is set: 1/16000-30 sec.

Mechanical Shutter: 1/250 sec.

Elec. 1st-curtain: 1/320 sec.

Soft-touch electromagnetic release

10-sec. delay, 2-sec. delay

Based on Canon testing standards.

In-body IS operation can be selected when using a non-IS lens.

• Always on
• Only for shot

• Y/P: Correction of angular camera shake (yaw/pitch); X/Y: Correction of shift- shake; Roll: Correction of roll shake.
• May not enable suitable coverage of the available stabilization area.
• *1: Coordinated control of lens optical IS and camera in-body IS

Ambience priority, standard, flash priority

Canon EX- and EL-series Speedlites

(1) Evaluative (Face Priority)

(2) Evaluative

(3) Average

Provided for EX- and EL-series Speedlites

±3 stops in 1/3- or 1/2-stop increments

1. E-TTL each shot

2. E-TTL 1st shot

*1 AE, flash metering, and WB do not change after the first shot in flash photography.

*2: Note that maximum continuous shooting speed is slower when certain lenses are attached and AF operation is set to Servo AF.

*3: Certain lenses support up to 30 shots/sec. Note that maximum continuous shooting speed is slower when other lenses are attached and AF operation is set to Servo AF.

*4: Certain lenses support up to 8 shots/sec. Note that maximum continuous shooting speed is slower when specific lenses AF operation is set to Servo AF.

*5: Continuous shooting speed is slower during flash photography (flash metering control: determined for each shot).

*6: Continuous shooting speed is slower with anti-flicker shooting.

*7: Continuous shooting speed is slower in flash photography with anti-flicker shooting.

*8: Not available when set to [Dual Pixel RAW: Enable].

* Maximum burst as measured under conditions conforming to Canon testing standards (High-speed continuous shooting + in One-Shot AF mode, ISO 100, and Standard Picture Style).

* Number of shots available varies depending on shooting conditions (including aspect ratio, subject, memory card brand, ISO speed, Picture Style, and Custom Function).

*1: For details on shooting conditions, see “21. Drive”.

*2: When using a 32 GB UHS-I card that conforms to Canon testing standards.

*3: When using a 32 GB UHS-II card that conforms to Canon testing standards.

*4: When set to [HDR shooting (HDR PQ): Disable].

*5: When set to [HDR shooting (HDR PQ): Enable].

Disable / Enable

* Can be used in conjunction with Auto Lighting Optimizer.

Dual Pixel CMOS AF II

±3 stops in 1/3- or 1/2-stop increments

Canon Log 3

If the maximum internal temperature is reached, this guidance is displayed, and the camera automatically stops (power off state).

Estimated recovery times are indicated below. These are affected by various factors such as ambient temperature, continued camera operation and the selected shooting resolution. The time until full record time is available, will vary with ambient temperature.

* Less continuous recording time is available if the camera cools down with Live View display active (without recording) than if it cools down while turned off.

Standard Movie Recording

Movie recording size overview

* Audio compression is restricted to [AAC] in Basic Zone modes.

* Only [AAC] is available for audio compression of IPB (Light).

*1: Generated from 7K oversampling.

*2: Playback frame rate.

*3: Recording frame rate.

*4: No audio is recorded for Miniature effect movies.

Canon Log: Off, HDR PQ: Of

• Bit rate only applies to video output, not audio or metadata.
• When audio data is set to [C.Fn 4-2 Audio compression: Enable] (audio: AAC recording).
• Movie recording stops when the maximum recording time per movie is reached.
• Sound is not recorded for approx. the last two frames when the compression method for movie recording quality is IPB (Standard) and the camera is set to [C.Fn 4-2 Audio compression: Enable] or IPB (Light) (audio: AAC). Moreover, the video and sound may be slightly out of sync when movies are played back in Windows.

Canon Log: On, HDR PQ: On

• Bit rate only applies to video output, not audio or metadata.
• When audio data is set to [C.Fn 4-2 Audio compression: Enable] (audio: AAC recording).
• Movie recording stops when the maximum recording time per movie is reached.
• Sound is not recorded for approx. the last two frames when the compression method for movie recording quality is IPB (Standard) and the camera is set to [C.Fn 4-2 Audio compression: Enable] or IPB (Light) (audio: AAC). Moreover, the video and sound may be slightly out of sync when movies are played back in Windows.

TFT colour, liquid-crystal monitor

3.0-inch (screen aspect ratio of 3:2)

Approx. 1.62 million dots

Approx. 100% vertically/horizontally

Manually adjustable to one of seven brightness levels

Clear View LCD II

• Anti-smudge coating applied.
• Anti-reflection coating not applied.

29 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Ukraine, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, Romanian, Turkish, Arabic, Thai, Simplified/Traditional Chinese, Korean, Malay, Indonesian, Japanese)

The white areas with no image data will blink.

Brightness and RGB

The Quick Control screen is accessed by pressing the Quick Control button during still photo shooting.

(1)Single image (select image)

(2) Select range

(3) All images in a folder

(4) All images on card

• Image browsing and image search can be based on ratings.
• Ratings-based image selections also possible with DPP.

(5) All found images (only during image search)

Except protected images

(1) Select images to erase

(2) Select range

(3) All images in folder

(4) All images on card

(5) All fo)und images (only during image search)

Not supported

Compliant to DPOF Version 1.1

IEEE 802.11b/g/n

DS-SS modulation (IEEE 802.11b)

OFDM modulation (IEEE 802.11g/n/a/ac)

2.4 GHz band

Frequency: 2412 to 2462 MHz

Channels: 1 to 11 channels

Images can be viewed, controlled, and received using a smartphone.

Remote control of the camera using a smartphone is possible depending on the Camera Connect specifications.

Images can be sent to a smartphone.

Firmware can be downloaded and saved to a card in the camera using Camera Connect.

The camera can be controlled via Wi-Fi® using EOS Utility.

Supported.

Still photos (RAW, C-RAW, HEIF, and JPEG) and movies (MP4) can be uploaded to image.canon server album.

With the image.canon server, images can be sent to social media or a photo album link can be sent (by the image.canon specifications).

Bluetooth Specification Version 4.2 compliant (Bluetooth low energy technology)

GFSK modulation

22 Custom Functions are settable.

Customizable Dials

• Main dial
• Quick control dial
• Control ring

• Up to six top-tier menu items and Custom Functions can be registered.
• Up to five My Menu tabs can be added.

My Menu tab overall operations

• Adding a tab
• Deleting tabs in a batch
• Deleting all tab items
• Setting the menu display

My Menu tab detailed operations

• Selecting a registered item
• Sorting registered items
• Deleting selected registered items
• Deleting registered items in a batch
• Deleting tabs
• Changing a tab name (16 ASCII characters)

Equivalent to Superspeed PLus USB (USB 3.2 Gen 2)

• For PC communication
• Terminal type: USB Type-C
• Shared with terminal for in-camera charging with USB Power Adapter PD-E1.
• In-camera Charging: Equivalent to USB type-C (5 V/1.5 A), but use should be restricted to USB Power Adapter PD-E1.

HDMI micro OUT terminal Type D (Resolution switches automatically) / CEC not compatible

• Images can be displayed through the HDMI output and on screen at the same time.
• Images will not be displayed unless [NTSC] or [PAL] is properly set according to the video system of the TV set.

Provided

3.5mm diameter stereo mini jack

3.5mm diameter stereo mini jack

Remote Switch RS-60E3 type terminal supported

• Compatible with the Wireless Remote Control BR-E1
• Compatible with infrared remote controls such as Remote Controller RC-6

Supported

LP-E6NH/LP-E6N/LP-E6*

• With the AC Adapter AC-E6N + DC Coupler DR-E6, AC power is possible.
• With the USB Power Adapter PD-E1, in-camera charging of LP-E6NH is possible.

Automatic battery check when the power switch is turned ON.

Displayed in 6 levels on top LCD panel.

• Battery level can be checked on the LCD panel and in the viewfinder. Battery Info display in Set-up Menu:
• Type of power source used.
• Remaining capacity (percentage of battery charge remaining).
• Recharge performance: (3-level display of battery's ability to hold a charge)

Approx. 0.4 sec.

• Based on CIPA testing standards.

Approx. 5.20 x 3.56 x 3.61 in. / 132.0 x 90.4 x 91.7 mm

• Based on CIPA standards.

Approx. 1.1 lbs (18.70 oz) Body Only

Approx. 1.3 lbs (21.59 oz) With battery,and memory card

32–104°F / 0–+40°C

85% or less
